2.3V 350f /Supercapacitor/Ultracap/Ultracapacitor/Edlc/ Electric Double Layer Capacitor

Add to Basket Share to :

Payment Terms 4

Inquire Now

* Send an Inquiry to this supplier.

Start Order

* Name your price
* Start order doesn't mean buying now

Supplier Info.

Company Name Chengdu Holy Tech Co., Ltd
Membership Free member
Registration Date2024.06.12
Country/RegionChina
CityChengdu
Contact Joyce(Ms.)

Report Item

Your report on Product(s) will be sent to EC21 Administrators once submitted.
Then, Administrators will investigate and then take appropriate actions.

Send Report Item

Contact Supplier

Product Attributes

- Place of Origin China
- Supply Type OEM Service
- Condition New
- Related Keywords Super Capacitor, Ultra Capacitor, Edlc, Ultracapacitor, Electrolytic Capacitors

Description by Manufacturer

10f supercapacitor 2.3v high Quality Radial Lead
Factory manufacturing and supply of 10f supercapacitor 2.3v high Quality Radial Lead.

Operating temperature : -25℃ ~ +65℃
Capacitance tolerance : -20% ~ +50%
Size : 10*20mm
Max ESR(AC) : 70(1kHzmΩ)
Max ESR(DC) : 140mΩ
Max Endurance Current: 0.20A
Max Peak Current: 4.79A
Max Leakage Current: 0.05(72hrs/mA)
Power Density: 2283(W/kg)
Max Energy: 0.0073(W.h)
Energy Density: 3.70(Wh/kg)

The 2.3V supper capacitor is suitable for electric tool, solar street light power supply and energy recovery.

Part Number	Rated Voltage(V)	Rated Cap. (F)	Size	ESR AC(1kHz/mΩ)	ESR DC(1kHz/mΩ)	Max. Peak Current(A)	Max. Leakage Current(72hrs)(mA)	Power Density(W/kg)	Max. Energy(w.H)	Energy Density (Wh.kg)
HLP2R3M106YS1020	2.3	10	10*20	70	140	4.79	0.050	2283	0.0073	3.70
HLP2R3M156YS1025	2.3	15	10*25	50	100	6.90	0.060	2591	0.0110	4.50
HLP2R3M226YS1030	2.3	22	10*30	50	100	7.91	0.065	1925	0.0162	4.90
HLP2R3M226YS1B20	2.3	22	12.5*20	6	10	6.95	0.085	1539	0.0162	4.70
HLP2R3M306YS1B25	2.3	30	12.5*25	50	100	8.63	0.110	1671	0.0220	5.80
HLP2R3M406YS1B30	2.3	40	12.5*30	40	80	10.95	0.130	1653	0.0294	6.12
HLP2R3M506YS1625	2.3	50	16*25	40	80	11.50	0.150	1101	0.0367	5.10
HLP2R3M656YS1630	2.3	65	16*30	35	70	13.47	0.180	1031	0.0478	5.43
HLP2R3M127YS1840	2.3	120	18*40	25	45	21.56	0.300	1056	0.0882	6.60
HLP2R3M227YS1860	2.3	220	18*60	15	27	36.46	0.550	1573	0.1616	10.81

Our advantage

We have a sound raw material cooperation system and cargo inspection mechanism.
Products with high stability, high temperature, small size, small tolerance and so on.
Product tolerances are strictly controlled between -15% to -10%.
We have the world’s most advanced production equipment, and improve the management process.
We can provide custom design of your needs and provide free sample for you.
Our products comply with the RoHS Directive and the factory conforms to the ISO 9001 management system.
