32 Inch Infrared Touch Screen

Add to Basket Share to :

Price

US$ 99

Min Order Quantity1 Piece
Supply Ability5000 piece per month
PortShenzhen
Delivery Lead Time2~7 working days after received the payment
Payment Terms 3
Required Quantity

Inquire Now

* Send an Inquiry to this supplier.

Start Order

* Name your price
* Start order doesn't mean buying now

Supplier Info.

Company Name U-Touch Technology Co., Ltd
Membership Free member
Registration Date2017.08.03
Country/RegionChina
CityDongguan
Contact Cerria Lee(Ms.)

Report Item

Your report on Product(s) will be sent to EC21 Administrators once submitted.
Then, Administrators will investigate and then take appropriate actions.

Send Report Item

Contact Supplier

Product Attributes

- Brand Name OEM
- Model Number UT-TSI-032JB
- Place of Origin China
- Supply Type In-Stock Items
- Condition New
- Type Infrared
- Multi-touch 6
- Mouse Function 10
- Power Supply 16
- Certification 32
- Color 40 points touch
- Related Keywords infrared touch screen, touchscreen, IR touch frame, IR touchscreen

Description by Manufacturer

Touch Frame Parameter:

Dimension	19mm width,8.7mm thickness (with frame, with glass)
Number of Touch Points	6,10,16,32,40 points touch
Touch Activation Force	no need extrusion,just need to touch the screen surface
Touch Durability	Unlimited
Resolution	32768*32768
Diver Free	HID*compatible,up to 40 touch points free driver
Linearity Deviation	±1mm
Fault Tolerance	Workable even 75% sensors are damaged
Frames per Second	Up to 450 fps
Typical Response Time	3~10ms
Light Transmission	100% without glass
Operating Systems	Windows7,8,10, Vista, XP, Mac OS, Linux, Android
Protocols	HID, TUIO, Flash
Re-development	Provide free SDK support C/C++,Java etc.
Warranty	1 year warranty

Electrical:

Power Supply	Single USB Connection
Ultra low power consumption	Operating≤2W, Stand By≤250mW
ESD	Per EN1000-4-21995;Level 4
	Contact Discharge 8kV
	Air Discharge 15kV

Environment:

Temperature	OperatingTemperature:-20°C~70°C
Temperature	StorageTemperature:-40°C~85°C
Humidity	Operating Humidity: 10%~90%RH(Non-condensing)
Humidity	Storage Humidity: 10%~90%RH(Non-condensing)
Certification	FC CE RoHS

Features:

♦ Waterproof, no blind zone for any size

♦ High-end Multi-touch experience (truly support 2,6 simultaneous touch points)

♦ Strong ambient light immunity up to150,000lux Fastresponse

♦ Support remote control and remote diagnosis

♦ USB plug &play driver free capability

♦ Easy intergration

Touch Frame Details

USB power supply: the connection is very easy as most of the modern equipment have the usb interface.

IR touch screen frame t-0160603-1_.jpg

Humanized design with the water proof function

IR touch screen frame-0161006-02_.jpg

Aluminum alloy frame,the width is 25.2mm and the thickness is 9.5mm without the glass.

IR touch screen frame T-0160603-3_.png

Installation steps:

Application

Digital Signage

Education Whiteboard

Vending machine

One machine

Newsstand and exhibition

Command center and conference room

Commercial transport

Touch Frame Packing

Certifications

FAQ

Q: Are you a factory?
A: Yes, we are a factory,we have our own production line.

Q: what's your products' quality control?
A: Our tenet is "Quality first, Prestige first". We are pay more attention to the beginning till the very end of the production. Our products have passed the CE & ROHS & ISO & FCC etc.

Q: What's your after-sale service?
A: We can offer 100% guarantee on our product. If any problems, you will get our reply within 24 hours.

Q: What's your MOQ?
A: Generally, our MOQ is 1 pcs. But the greater the quantities , the bigger the discount .

Q: Could you offer the OEM service?
A: Yes, we can provide the OEM service if our customer requested.

Q: What's the warranty? Can we required longer warranty service?

A: We provide 1 year warranty. Extended warranty is offered with 5% extra cost for each year.

Q: How to make the order?

A: Send detailed inquiry to us, then we will reply you with the Proforma Invioce. Make the payment after you confirm the PI. We ship out the products by express or by sea within 7-15 days after we receive the payment. Then you will get the cargos soon.

Q: How to contact us?

A: Email: sale6(at)u-touch.com.cn

Whatsapp: 008618824867022

Tel: 867522613456

Others

Certificates

- CE QCT14LC0801E
- FCC QCT14LC0802E

Price

Price US$ 99 / Piece

Packaging & Shipping

- Packing1 pieces per carton
- Packaging Size85 x 10 x 10 ( Millimeters)
- Package Weight 3 ( Kilograms )
- Delivery Lead Time2~7 working days after received the payment
- Minimum Order 1 Piece
- Supply Ability5000 piece per month
- Total quantity in Stock1 - 10
- Delivery PortShenzhen
- HS Code8471906000
- Shipping Career

Product Image

Product Video

Infrared Touch Screen Related Products

Main Export Markets

- U-Touch Technology Co., Ltd is mainly exporting to Asia, Europe, North America, South America, Australia, Africa

Company Profile

About U-Touch Technology Co., Ltd

Membership Free member
Registration Date2017.08.03
Country/RegionChina
CityDongguan
Contact Cerria Lee(Ms.)

About Huizhou U-Touch Technology Co., Ltd

U-Touch is a professional manufacturer develops multi-touch hardware for interactive solutions. Products involving interactive flat panel, IR touch frame, interactive whiteboard, digital signage and led smart board are extremely in original design and remarkable quality. U-Touch touchscreen experience has consistently stood for quality, reliability and innovation. Touch frames with sizes from 15" to 580" are available for variety of solutions. OEM & ODM is provided for custom-designed solutions as per your requirements.

Video

< null >

Tags: null

Buying Categories

- Television >> Consumer Electronics

Selling Categories

- Computer Hardware & Software >> Monitors
- Office & School Supplies >> Educational Equipment
- Office & School Supplies >> Presentation Equipment

Keywords

interactive flat panel , interactive whiteboard , ir touch frame , etc

Registration Date	2017/08/03(Year/Month/Date)
Buyer / Seller in EC21	Seller
Business Type	Manufacturer
Year established	2007
Employees total	51 - 100
Annual revenue	USD 2,000,001 - 5,000,000

Contact Information Order Credit Report

Company	U-Touch Technology Co., Ltd
Address	Floor 4, Building B, No.216, Shaxin Rd, TangXia TownDongguanGuangdongChina
Phone	86 - 752 - 2613456
Fax	86 - 752 - 2566399
Contact	Cerria Lee / Sales Manager
