Automatic Architecture Automative Windowshield Ceramic On Glass Sheet Screen Printing Machine

Add to Basket Share to :

Price

US$ 35000

Min Order Quantity1 Set
Supply Ability100sets/month
PortSHENZHEN
Delivery Lead Time30 days
Payment Terms 3
Required Quantity

Inquire Now

* Send an Inquiry to this supplier.

Start Order

* Name your price
* Start order doesn't mean buying now

Supplier Info.

Company Name Shenzhen Xinzhong Plastic Package Machine Co.,Ltd.
Membership Free member
Registration Date2021.04.24
Country/RegionChina
CityShenzhen
Contact greenery pan(Ms.)

Report Item

Your report on Product(s) will be sent to EC21 Administrators once submitted.
Then, Administrators will investigate and then take appropriate actions.

Send Report Item

Contact Supplier

* From

Ms.greenery pan

Shenzhen Xinzhong Plastic Package Machine Co.,Ltd.

* Buying Product

Category : Printing Machinery

- Please enter your specific buying item.
e.g. 42inch LCD TV, leather executive chair

* Messages Use English only Max. 2000 characters. (Min. 20)

Send

EC21.com does not guarantee the validity of product information or the credentials of sellers.

Product Attributes

- Place of Origin China
- Supply Type In-Stock Items
- Condition New
- Color White
- Color & Page Single Color
- Plate Screen Printer
- Type screenprinter
- Usage glassprint
- Related Keywords glass screen printing, flat glass print machine, flat glass sheet printing

Description by Manufacturer

Automatic Architecture Automative Windowshield Ceramic On Glass Sheet Screen Printing Machine

Application:
Applicable to printing the construction glass, automobile glass，decorative glass,engineering glass etc.

Features:

● Automatic operation: loading ,pre-orientation , precise orientation,printing ,detection and glass unloading conveying dryer , convenient to operation .

● Imported synchro anti-sliding lifting conveyor which makes the conveyor stable ,less noisy and durable ,also makes sure the assemble and adjustment of conveyor belt convenient and easy to maintain.

● Secondary position, makes sure the contraposition of various shapes of glass precise.

● Even pressure and automatic compensation system ensure the fine and precise printing .

● Imported linear sliding rail and synchronous belt are for the printing drive,ensure stable operation and continuously variale transmission.

● PLC system adopted to control operation.

● Automatic alarm system and pneumatic mechanical safe protection device to ensure safe operation.

● Optional servo system for the printing and off-screen, guarantee high speed ,high precision and stable printing.

Techincal Data and models

Techincal Data	1220GL(mm)	1326GL(mm)	1726GL(mm)	2030GL(mm)	2436GL(mm)	2445GL(mm)	2551GL(mm)	2860GL(mm)	3060GL(mm)
MAX SIZE	1200*2000	1300*2600	1700*2600	2000*3000	2400*3600	2400*4500	2500*5100	2800*6000	3000*6000
MIN SIZE	500*700	500*700	500*700	600*800	700*1000	900*1200	900*1200	900*1200	900*1200
MAXSCREEN SIZE	1800*2900	1900*3300	2300*3300	2600*3700	3000*4300	3000*5800	3100*5800	3400*6700	3600*6700
PRINTING TABLE SIZE	1500*2600	1600*3000	2000*3000	2300*3400	3700*4000	3700*5500	2800*5500	3100*6400	3300*6400
SYCNGHRONUZER VALID RANGE	0~60	0~60	0~60	0~60	0~60	0~60	0~60	0~60	0~60
THICKNESS	2.5~19	2.5~19	2.5~19	3~19	3~19	3~19	3~19	3~19	3~19
TOTAL POWER	7.2KW	12KW	12KW	12.7KW	12.7KW	12.7KW	12.7KW	16KW	16KW
TOTAL WEIGHT	3000kg	4500kg	5000kg	6000kg	7000kg	8000kg	8500kg	11000kg	12000kg
MACHINE SIZE	8200*200	10000*2700	10000*3100	11400*3200	12600*3800	1512*3200	9600*7500	19800*4100	19800*4300

Price

Price US$ 35000 / Set

Packaging & Shipping

- Packingplastic package
- Delivery Lead Time30 days
- Minimum Order 1 Set
- Supply Ability100sets/month
- Total quantity in Stock11 – 20
- Delivery PortSHENZHEN
- HS Code84431929
- Shipping Career

Product Image

Automatic Architecture Automative Windowshield Ceramic On Glass Sheet Screen Printing Machine

Glass Screen Printing Related Products

Download Product Brochure

102.pdf (0.81 Mb) 104.pdf (0.79 Mb) t103.pdf (0.68 Mb) 1.pdf (0.79 Mb) HEAT PRESS.pdf (0.8 Mb)

Company Profile

About Shenzhen Xinzhong Plastic Package Machine Co.,Ltd.

Membership Free member
Registration Date2021.04.24
Country/RegionChina
CityShenzhen
Contact greenery pan(Ms.)

Shenzhen Xinzhong Plastic Packaging Machinery Co., Ltd. is an innovative enterprise integrating R&D, production, sales and service. Learning progress, continuous innovation and leading the industry are our unshakable goals.

Shenzhen Xinzhong Plastic Packaging Machine Co., Ltd. is a high-tech enterprise specializing in developing special full-automatic screen printing and hot stamping machine for bottles/caps. Its products are mainly used for cosmetic bottles, pharmaceutical bottles, wine bottles, cleaning bottles, caps and other cylindrical objects. The main products are full-automatic screen printing machine, hot stamping machine, assembly machine, spraying machine, heat transfer machine and other series of products.

Shenzhen Xinzhong Plastic Packaging Machine Co., Ltd. was founded in 2001, but its founder had developed the first fully automatic 5-color UV screen printing production line in mainland China as early as 1997, which shortened the gap between the domestic automatic screen printing equipment and foreign advanced level. After startup and through several years of continuous efforts, Xinzhong has also made gratifying research and development results, and many new projects have been continuously promoted to the market. Xinzhong continue to expand sales around the world, the latest developed series of automatic spraying machine for wine bottles and caps, servo screen printer, assembly machine are the No.1 in China.

Xinzhong occupy area of 15,000 square meters, meanwhile it is an innovative enterprise, which integrated with research and development, production, sales and service. Xinzhongs high-quality service team are protecting the rights and interests of customers at home and abroad, and for the sake of customers provide professional technical training.
