ATOMETAL developed for protection against corrosion in industrial settings. It provides a quick and nearly complete corrosion maintenance program for a wide range of industrial materials. This product is designed to build up a non-thermosetting ceramic coating on the surface of the material to effectively block almost all types of corrosive factors.
Product summery
AM-A
Ceramic-metallic Rebuilding Grades
To repair and strengthen welded parts of steel, damaged area, worn-out steel surface of ships, equipment, machinery, structures, pipes, tanks, etc.
AM-C
Ceramic-metallic Corrosion Resistance Coating Grades
For coating applications on a wide range of industrial materials to protect from corrosion and erosion, especially on marine facilities.
Specific Grades effective to different coating work conditions
CERACOT
Ceramic-metallic Rebuilding Grades of the small packaged set
For repairing and reconditioning of damaged area, worn-out steel surface of households, car parts, small-sized equipment, small-sized machinery and etc.
Atometal Benefits in comparison to other conventional corrosion protection systems :
-
does not break down or change under severe environmental surroundings. It virtually guarantees an enduring corrosion protection system which will extend the life of your valuable investments.
-
non-flammable and pollution-free. It is simple to use and can be easily adapted to work within a variety of settings and environmental conditions.
-
Complete and Efficient for Long Life for 30years.
-
Extensive variety of application, it is applicable to damp and wet surface.
-
Environmentally friendly due to low volatile organic compound level.
-
Simply benefited by single cost system.
-
Long term cost saving system due to longer durability.
Application of Atometal Ceramic Corrosion Resistance Coating(AM-C) include Repairing and Strengthening(AM-A):
-
Ocean Structures and Ships
-
Piping system and storage Tanks
-
Gas and Petroleum Plant and Facilities
-
Dam draining Gates and other steel structures
-
Factory and Power Plant
-
Bridges and high Level Roads
-
Steel Towers and Steel Structures
-
Waterproof & Anti-corrosion of Concrete water Tanks and Water and Sewage Plant
Physical Property and Chemical Stability of ATOMETAL(AM-A)
|
Test Description
|
Test Result
|
|
Specific gravity
Adhesive strength
Rockwell hardness
Bending
Pressure Test
Thermal Fatigue
Electrical Resistance
Impact Energy
Resistance to heat
Resistance to Chemicals
Resistance to Oil
Resistance to Gasoline
Resistance to ozone
Resistance to impact
Resistance to salt spray
Flexibility
Toxicity
|
2.0 - 2.2
160 - 220 kgf/cm2
100-114 HRR scale
no failure at R=1.5t
no failure at 200kgf/cm2
-35°C to 120°C for 3cycles : No cracking
4.0 x 010 ohmm
8.5J at R.T.
250°C
No effect after 168hrs in 5% H2SO4 or NaOH
No effect after 168hrs in Kerosine
No effect after 168hrs
No effect after 48hrs in ozone 10ppm, 40°C
No defects by 73.5kN hammering
No effects in 3.5% NaCl, 4000hrs accelerated test
No cracks by mandrel bend test, Ø10mm bar
No toxic after cured |
|
Physical Property and Chemical Stability of ATOMETAL(AM-C)
|
Test Description
|
Test Result
|
|
Specific gravity
Adhesive strength
Rockwell hardness
Bending
Pressure Test
Thermal Fatigue
Electrical Resistance
Impact Energy
Resistance to heat
Resistance to Chemicals
Resistance to Oil
Resistance to Gasoline
Resistance to ozone
Resistance to impact
Resistance to salt spray
Flexibility
Toxicity
|
1.6 - 1.8
160 - 220 kgf/cm2
100 -114 HRR scale
no failure at R=1.5t
no failure at 200kgf/cm2
-35°C to 120°C for 3cycles : No cracking
4.0 x 010 ohm m
8.5J at R.T.
200°C
No effect after 168hrs in 5% H2SO4 or NaOH
No effect after 168hrs in Kerosine
No effect after 168hrs
No effect after 48hrs in ozone 10ppm, 40°C
No defects by 73.5kN hammering
No effects in 3.5% NaCl, 4000hrs accelerated test
No cracks by mandrel bend test, Ø10mm bar
No toxic after cured |
|
Mix proportion (at ambient temperature 20°C) : Base to Hardener : 5 to 1 by weight, 3 to 1 by volume
|
Grade
|
Volume
Solids
|
Pot Life
|
Curing time
|
Shelf Life
|
|
AM-A
|
93%
|
20-30 Min
|
24Hr
|
1 Year
|
|
AM-C
|
87%
|
30-40 Min
|
24Hr
|
1 Year
|
|
Products List
|
Product Name
|
Description
|
Packing units
|
|
AM-A
|
Repairing and strengthening Adhesives for Vessels, welded part of steel Tanks and steel Pipes, Machines, Iron Plant
|
1kg
|
|
AM-A-Q
|
Repairing and strengthening quick curing Adhesives for Vessels, welded part of steel Tanks and steel Pipes, Machines, Iron Plant |
1kg
|
|
AM-C-C
|
Waterproof and anti-corrosion coating for Cement-concrete Tanks, filter plant |
1kg, 20kg
|
|
AM-C-B
|
Anti-corrosion coating for Bridge guider & steel parts, High-level road guider |
1kg, 20kg
|
|
AM-C-E
|
Anti-corrosion coating for Underground steel pipe line |
1kg, 20kg
|
|
AM-C-I
|
Anti-corrosion coating for Civil steel-structures in open-air
|
1kg, 20kg
|
|
AM-C-O
|
Anti-corrosion coating for Oil and Gas Tanks, Oil and Gas Pipe Line
|
1kg, 20kg
|
|
AM-C-R
|
Anti-corrosion coating for Harbor loading Heavy Equipment, special Vehicles |
1kg, 20kg
|
|
AM-C-T
|
Anti-corrosion coating for Acid-chemical Tanks, the bottom of Vessels, Ocean steel structures |
1kg, 20kg
|
|
AM-C-U
|
Anti-corrosion coating for Building exterior
|
10kg
|
|
AM--P
|
Primer paint for Steel structures
|
22kg
|
|
AM-CP
|
Primer paint for Cement-concrete structures |
22kg
|
|
Ceracot
|
Multi-purposes Repairing and strengthening Adhesives |
60g, 100g
|
|
KHM-129
|
Exclusive diluent for AM-C series |
200cc/can,
4 ltre
|
|
Reinforcing elastic cotton tape
|
Winding and wrapping material for pipes and etc., use with AM-C |
150mm x 2000mm / roll
|
|
Merits of item by item
|
Product
|
Product Description
|
Product Description
|
| AM-A |
Repairing and strengthening Adhesives for Vessels, welded part of steel Tanks and steel Pipes, Machines, Iron Plant |
Strong adhesive strength and acts as a cold welding type and adhesion in underwater structures |
AM-A-Q
|
Repairing and strengthening quick curing Adhesives for Vessels, welded part of steel Tanks and steel Pipes, Machines, Iron Plant
|
Fast curing, strong adhesive strength, acts as a cold welding type, adhesion in underwater structures |
AM-C-C
|
Waterproof, anti-corrosion coating for Cement-concrete Tanks, filter plant
|
after cured no toxic and can be permeable to body for reinforcement and high durability |
| AM-C-B |
Anti-corrosion coating for Bridge and high-level road guider and steel parts
|
has optimum elasticity and high carbonation resistance property |
AM-C-E
|
Anti-corrosion coating for Underground steel pipe line
|
Anti-bacterium and electrical insulating coating |
| AM-C-I |
Anti-corrosion coating for Civil steel-structures in open-air |
High carbonation resistance, weatherability property |
| AM-C-O |
Anti-corrosion coating for Oil and Gas Tanks, Oil and Gas Pipe Line
|
High chemical resistance property |
| AM-C-R |
Anti-corrosion coating for Harbor loading Heavy Equipment, special Vehicles
|
Has optimum elasticity and high carbonation resistance property |
AM-C-T
|
Anti-corrosion coating for chemical Tank, Vessels, Ocean steel structures
|
High chloride resistance property and high impact strength |
| AM-C-U |
Anti-corrosion coating for Building exterior
|
UV protection and improvement of durability |
| AM--P |
Primer paint for Steel structures |
High rust protection property, Improvement of adhesive strength for main coating |
| AM-CP |
Primer paint for Cement-concrete structures |
High permeate to body for reinforcement, improvement of adhesive strength for main coating |
| Ceracot |
Multi-purposes Repairing and strengthening Adhesives |
Fast curing, strong adhesive strength, acts as a cold welding type, adhesion in underwater structures |
|

|
