Product Attributes

- Brand Name Kailong
- Place of Origin China
- Supply Type OEM Service
- Condition New
- Color Silver
- Related Keywords flow meter, liquid flow meter, Gear flow meter, oil flow meter

Description by Manufacturer

1. Product Introduction

Gear flow transmitter belongs to a kind of volumetric flow transmitter and can be used for measuring volume

and flow precisely. The flowing medium makes the gear engage and rotate. Under the flowing effect of fluid,pressure difference is formed between the inlet and outlet of instrument. One pair of gears can rotate freely without the need of power supply. The empty cavity between gears is filled with liquid, which is discharged through rotation. The liquid flowing through instrument and liquid flow can be known through measuring the number of revolutions of gear.

Typical applications:

Measurement of resin and glue

Measurement of hydraulic oil, lubricating oil and grease

Measurement of fuel oil

Measurement of printing ink and asphalt

Measurement of liquid nitrogen, refrigerant and solvent

Measurement of edible oil, fish oil and food canning

Measurement of chemical fluid or fluid with corrosion resistance requirements

Fluid quantitative control system

small oval gear meter.jpg

Thread connection Tri-clamp connection Flange connection

2.Technical Specification Table

Item	Gear Flow Transmitter
Accuracy	0.5% / 1%
Measuring range	From 0.6-50L/H to 2000-20000L/H
Diameter (MM)	DN2-DN32
Range ratio	1:100( 1%) , 1:10 (0.5%)
Max viscosity	up to 1000 Pa.s
Working temp.	-15-80 ℃ (customized , -15-200 ℃ )
Output	4-20mA / Pulse Option: RS485
Press	5MPa, max pressure 40MPa
Power	24VDC
Connection	Thread or flange
Materail	Meter body :SUS304 Rotor: SUS304 Flange: SUS304
Protection grade	IP65

3.Technology Parameter

Model	Diameter	Flow range (L/H)	Interface	Max pressure (bar)	Temperature	Accuracy
GF-2	2mm	0.6-50	G1/4	50 bar	-15-80 °c	1% 0.5%
GF-4	4mm	5-200	G1/4
GF-6	6mm	10-500	G1/2
GF-10	10mm	50-1200	G1/2
GF-15	15mm	200-3000	G3/4
GF-25	25mm	1000-12000	G1
GF-32	32mm	2000-20000	G1-1/4

Packaging & Shipping

4. Packing and shipping

Price

Price US$ 500 / Set

Packaging & Shipping

- PackingWooden case
- Delivery Lead Time3-5 days
- Minimum Order 1 Set
- Supply Ability500 sets one month
- Total quantity in Stock301 – 500
- Delivery PortTianjin
- HS Code90261000
