EPS Sandwich Wall Panel Machine

Add to Basket Share to :

Price

US$ 5800

Min Order Quantity1 Set
Portqingdao
Delivery Lead Time15 working days after payment
Payment Terms 1
Required Quantity

Inquire Now

* Send an Inquiry to this supplier.

Start Order

* Name your price
* Start order doesn't mean buying now

Supplier Info.

Company Name Shandong Tianyi Machinery Co.,Ltd.
Membership Free member
Registration Date2023.05.05
Country/RegionChina
CityJining
Contact tarcy zhao(Ms.)

Report Item

Your report on Product(s) will be sent to EC21 Administrators once submitted.
Then, Administrators will investigate and then take appropriate actions.

Send Report Item

Contact Supplier

* From

Ms.tarcy zhao

Shandong Tianyi Machinery Co.,Ltd.

* Buying Product

Category : Cap Making Machinery

- Please enter your specific buying item.
e.g. 42inch LCD TV, leather executive chair

* Messages Use English only Max. 2000 characters. (Min. 20)

Send

EC21.com does not guarantee the validity of product information or the credentials of sellers.

Product Attributes

- Brand Name Tianyi
- Place of Origin China
- Supply Type manufacturer
- Condition New
- Color baseonyou
- Related Keywords EPS

Description by Manufacturer

Overall dimension (LxWxH)mm 3030x1190x2500 Total power(kw) 23.75 Hydraulic working pressure(Mpa) 8 Capacity of hydraulic tank(L) 70

Maximum hydraulic working pressure(Mpa) 16

Power of vibration system(kw) 0.75

Power of heating system(kw) 20

Structural composition Host machine, hydraulic system, power distribution system, heating system,vibration system, core tubles

Raw material of lightweight wall panel

NO.	Material	Price(¥)/m²
1	Cement	10
2	Coal ash	0.5
3	Sand	0.4
4	Additive	1.5
5	Labor cost	2
6	water and electricity	0.5
7	Other cost	0.1

Finished products

Test ltems	National standard	Actual index
Compressive strength	≥3.5MPa	≥3.7MPa
Drying shrinkage	≤0.6mm/m	0.37mm/m
Hanging force	≥1000N without 0.5mm crack in 24 hours	≥1000N without 0.5mm crack in 24 hours
Shock resistance	without crack shocked by 30Kg sandbag for 5 times	without crack shocked by 30Kg sandbag for 5 times
Sound insulation	≥35dB	43dB

Why choose us

Price

Price US$ 5800 / Set

Packaging & Shipping

- Packingqingdao
- Delivery Lead Time15 working days after payment
- Minimum Order 1 Set
- Total quantity in Stock11 – 20
- Delivery Portqingdao
- Shipping Career

Product Image

Download Product Brochure

wall panel production line.pdf (1.12 Mb)

Company Profile

About Shandong Tianyi Machinery Co.,Ltd.

Membership Free member
Registration Date2023.05.05
Country/RegionChina
CityJining
Contact tarcy zhao(Ms.)

Shandong Tianyi Machinery Co.,Ltd a national high -tech enterprise,covers an area of 330 mu and owes a modernized standard workshop of 80000 m.The company is a leading enterprise which is devoted to research and development of new equipment and manufacture and provision of integrated solution of solid waste;the leading products include light wall board production line,foamed cement insulation board production line,gypsum wall board forming machine,which reaches above 40% of the market share in the industry;the products are sold around the nation and are exported to more than 30 nations and areas,such as Russia,Indonesia and Syria,etc.;the company has a high-quality customer base containing more than 6000 enterprisesthe above- mentioned achievements made Tianyi Machinery the leading force in the sense of capacity of wallboard machinery and the company has gradually become an important technical research and development center for wallboard machinery in the world.
The company conforms to the demand of social development,bravely undertake social responsibility,actively pursuit the transformation and updating of enterprise,with the national promoting to develop precast building opportunity,transform target toBuilding Industrialized Modernization,make efforts to fulfill the mission of Serve for Precast Building,actively devotes to the R&D promotion application of the new style house,The company has been awarded honorary title National Key High-tech Enterpriseby Science and Technology Ministry,National Precast Building Industrialized Base by Housing Ministry,National resources comprehensive utilization demostration baseby National Development and Reform Commission.
