Fluke RSE600/C 60HZ - Fixed Mount Thermal Imager with Case, HS1 - 640 X 480 Resolution, 60 Hz

Add to Basket Share to :

Price

US$ 9255.55 ~ 12955.95

Min Order Quantity1 Unit
PortChangi
Delivery Lead Time1-2
Payment Terms 4Wise
Required Quantity

Inquire Now

* Send an Inquiry to this supplier.

Start Order

* Name your price
* Start order doesn't mean buying now

Supplier Info.

Company Name Toolshed Ltd
Membership Free member
Registration Date2025.02.26
Country/RegionSingapore
CitySingapore
Contact Hendrik Norsan(Mr.)

Report Item

Your report on Product(s) will be sent to EC21 Administrators once submitted.
Then, Administrators will investigate and then take appropriate actions.

Send Report Item

Contact Supplier

Product Attributes

- Brand Name Fluke
- Model Number RSE600/C 60HZ
- Place of Origin Singapore
- Supply Type OEM Service
- Condition New
- Power Electronic
- Usage Universal Testing Machine
- Related Keywords Fluke Thermal Imager, Thermal Imager, Analyzer, Calibration, Temperature

Description by Manufacturer

Manufacturer Specs

Fluke RSE600/C 60HZ Specifications
Infrared resolution	640 x 480 (307,200 pixels)**
IFOV with standard lens (spatial resolution)	0.93 mRad
Field of view	34 °H x 24 °V
Minimum focus distance	15 cm (approx. 6 in)
Camera focus options	Focus is adjusted in SmartView R&D™ desktop software
IR-Fusion technology	Yes, in SmartView R&D™ desktop software. Five modes of image blending (AutoBlend™ mode, Picture-in-Picture (PIP), IR/Visible alarm, Full IR, Full visible light) add the context of the visible details to your infrared image
Interfaces for image/data transfer	Supported in camera data ports: GigE Vision
Thermal sensitivity (NETD)	≤ 0.040 °C at 30 °C target temp (40 mK)*
Level and span	Smooth auto and manual scaling, in SmartView desktop software
Fast auto toggle between manual and auto modes	Yes, in SmartView R&D™ desktop software
Fast auto-rescale in manual mode	Yes, in SmartView R&D™ desktop software
Minimum span (in manual mode)	0.1 °C (0.18 °F), in SmartView R&D™ desktop software
Minimum span (in auto mode)	<1.0 °C (<1.8 °F), in SmartView R&D™ desktop software
Built-in digital camera (visible light)	5 megapixel industrial performance
Frame rate	60 Hz
Digital zoom	Variable up to 16x in SmartView R&D™ desktop software
Temperature measurement
Temperature measurement range (not calibrated below -10 °C)	-10 °C to +1200 °C (14 °F to +2192 °F)
Accuracy	± 2 °C or ± 2 %, whichever is greater
Autocapture	Yes, in SmartView R&D™ desktop software
Reflected background temperature compensation	Yes, in SmartView R&D™ desktop software
Transmission correction	Yes, in SmartView R&D™ desktop software
Color palettes
Standard palettes	11: Rainbow, Iron, Gray, RContrast, Rain900, Rain, Fire, Yellow, GrayRed, MidGray, Y-Glow
Ultra Contrast™ palettes	3: Histogram equalization, Auto Plateau equalization, Plateau equalization
Analysis tools
Custom markers	Spot, line, box, circle
Color alarms (temperature alarms)	Yes, in SmartView R&D™ desktop software-high temperature, low temperature, and isotherms (within range)
Image analysis tools	Ruler, measure line, measure angle, note, pins
Real-time trend	Point trend, area trend, mix trend, profile trend, boxline trend
Customizable reports	Display the information you need based on your application
Center-point temperature measurement	Yes, in SmartView R&D™ desktop software
Spot temperature	Yes, in SmartView R&D™ desktop software-hot and cold spot markers
User-definiable spot markers	Unlimited user-definable spot markers, in SmartView R&D™ desktop software
Center box	Expandable-contractible measurement box with MIN-MAX-AVG temp display, in desktop software
Best possible *Option to output 320x240 infrared data through GigE Vision

Tech Specs

Thermal Imagers/Building and Industrial Thermal Imagers Template
Detector Size	640 x 480 Sensor
Thermal Sensitivity	40 mK (NETD)
Temperature Range Max	2192 F
Temperature Range Min	14 F
Image Frequency	60 Hz
Field of View	34 x 24 Degrees
IR/Overlay Fusion Image	Yes
Video Output	Yes
Focus	Adjustable
Laser Spot	No
Picture in Picture	Yes
Video Recording	Yes
Moveable Spots	Yes
Minimum Focus Distance	6 M
Accuracy	± 2 °C or ± 2 %, whichever is greater
IR Digital Zoom	Yes
Intrinsically Safe	No
Test Equipment General Attributes
Warranty	2 YEARS
IP Rating	IP67
Product Weight	2.2 LBS
Product Height	3.3 IN
Product Length	6.5 IN
Product Width	3.3 IN
Shipping Weight	11.00 LBS
HTS/Schedule B Number	9027.50.4020
ECCN Number	6A003.b.4.b
Shipping Height	16.00 IN
Shipping Length	18.00 IN
Shipping Width	7.00 IN

Price

Price US$ \ 9255.55 ~ 12955.95 / Unit

Packaging & Shipping

- PackingNew Box
- Delivery Lead Time1-2
- Minimum Order 1 Unit
- Delivery PortChangi
- Shipping Career

Product Image

Fluke RSE600/C 60HZ - Fixed Mount Thermal Imager with Case, HS1 - 640 X 480 Resolution, 60 Hz
