10000L 20000L 30000L 50000L Commercial/industrial beer fermenter stainless steel beer yeast fermentation tank

Model	HG-FJ-30000L
Useful capacity	30000L
Gross capacity	36000L
Material	SUS304
Thickness	Inner (SUS304)thickness: 5.0mm; External-Jacket(SUS304) thickness: 2.0mm
Application	Brewery
Cooling method	Three-stage Dimple jacket plate
Cleaning way	CIP in situ cleaning, with rotary spray cleaning ball
Insulation	Polyurethane-thickness: 100mm
Accessories	Sample valve, Pressure gauge, Breath valve, Temperature gauge, Top manhole, Washing ball, Butterfly valves, CIP Arm, Hop port, Discharge arm and so on.

six-year warranty, only for tanks, excluding electrical appliances, wearing parts such as cushions, seals, etc. (mixing
seals,pump seals, butterfly valves and other valve seals),pumps.The price does not include electrical appliances, etc.

 Fermenter advantage :
1). 304 stainless steel plate as a whole, and our stainless steel plate manufacturer is the best in China .2). The cooling
efficiency.
of Maitreya plate jacket is greatly improved.
3). Two stage cooling mode .
4). The insulation layer material is high-grade polyurethane with a thickness of 80mm.
 5). Polishing accuracy up to Ra0.4μ m .
6). Strict tank pressure test .
7). Energy conservation and pollution emissions.

5000L Description of fermenter :

5000L fermentation tanks suitable for hotels and restaurants and brewery. The fermentation tanks use certified stainless steel material. All tanks and jackets inspected and pressure tested to 3 times operatiing pressure. The dimension of the tanks can be designed according to customer’s requirement. Tank design pressure is 0.4Mpa and testing pressure is 0.3Mpa.

Item	Production capacity	Volume in US Gallon	Heating area	Tank diameter	Height
HG-100	100L/day	26US Gallon	0.5㎡	650mm	1500mm
HG-200	200L/day	53US Gallon	0.8㎡	850mm	1600mm
HG-300	300L/day	79US Gallon	1.2㎡	960mm	1700mm
HG-400	400L/day	106US Gallon	1.5㎡	1060mm	2000mm
HG-500	500L/day	132US Gallon	1.8㎡	1160mm	2300mm
HG-5BBL	5BBL/day	155 US Gallon	1.9㎡	1200mm	2350mm
HG-600	600L/day	158US Gallon	2.0㎡	1220mm	2350mm
HG-700	700L/day	185US Gallon	2.4㎡	1260mm	2380mm
HG-800	800L/day	212US Gallon	2.5㎡	1260mm	2400mm
HG-7BBL	7BBL/day	216US Gallon	2.5㎡	1280mm	2450mm
HG-1000	1000L/day	264US Gallon	2.6㎡	1360mm	2500mm
HG-10BBL	10BBL/day	310 US Gallon	2.8㎡	1460mm	2700mm
HG-1500	1500L/day	396US Gallon	3.2㎡	1520mm	2900mm
HG-2000	2000L/day	528US Gallon	3.6㎡	1560mm	2850mm
HG-2500	2500L/day	660US Gallon	3.8㎡	1650mm	3200mm
HG-3000	3000L/day	792US Gallon	4.5㎡	1760mm	3800mm
HG-4000	4000L/day	1057US Gallon	4.9㎡	1900mm	4100mm
HG-5000	5000L/day	1320US Gallon	7.2㎡	1960mm	4400mm

1.How to achieve temperature control? The PLC or digital dispalyer could control the temperature by connecting with the PT 100 sensor.The brewing tanks with rock wool to keep warm,the fermenters and bright beer tank with PU as cooling jacket to keep cool.

2.Which countries your products are exported to?
Our stainless steel microbrewery equipment are sold all over the world and with related certifications.

 3.How to use your machine?
 We have paper instructions in English, and we will teach till you do it well.

4.How long is your delivery time?
Usually it takes about 50 working days to manufacture a brewery.Depending on the size of the brewery,the amount of custom designed equipment,our general workload and the way of shipping this period can be shorter or longer.

5.Do you provide after-sales service?
 Yes,we could provide after-sales service.We have many professional engineers, they can go to
your place and teach your person installation and brewing

1. Container loading(20GP/40GP/40HQ)
2. Packed with plastic film and iron frame for main tank.Fittings use iron cabinet.
3. Customer's requirements available.

1.Pre-service :

-Layout:Sent us your building floor plan, or the sketch, or tell us the size (length, width, height), we will offer you an
equipment footprint according to your requirement. -Technical Drawings : We will offer Technical Drawings of each tank based on the equipment layout . -3D effective sketch: We will 3D effective sketch to make sure ensure you have a more intuitive experience.

2.After service :

We guarantee the quality of the electrical elements within one year and tanks body within 1 years. If the electrical elements go wrong without artificial factors within one year, we will freely provide them or maintain them for you. After warranty, if you need to change parts, we will kindly provide you with the best price or maintain it in your site. Whenever you have technical question in using it, we will freely do our best to support. We can also dispatch our engineer to your brewery to install and adjust the machines for you. He can also train your staff to use the equipment.
