S7-L Smart Dust Sensor PM2.5 Sensor Module Dust Concentration Sensor Air Quality Sensor Module

Add to Basket Share to :

Price

US$ 5

Min Order Quantity1000 Unit
Payment Terms 1
Required Quantity

Inquire Now

* Send an Inquiry to this supplier.

Start Order

* Name your price
* Start order doesn't mean buying now

Supplier Info.

Company Name Guangzhou Luftmy Intelligence Technology Co., Ltd
Membership Free member
Registration Date2020.05.08
Country/RegionChina
CityGuangzhou
Contact DAI MO(Ms.)

Report Item

Your report on Product(s) will be sent to EC21 Administrators once submitted.
Then, Administrators will investigate and then take appropriate actions.

Send Report Item

Contact Supplier

* From

Ms.DAI MO

Guangzhou Luftmy Intelligence Technology Co., Ltd

* Buying Product

Category : Sensors

- Please enter your specific buying item.
e.g. 42inch LCD TV, leather executive chair

* Messages Use English only Max. 2000 characters. (Min. 20)

Send

EC21.com does not guarantee the validity of product information or the credentials of sellers.

Product Attributes

- Place of Origin China
- Supply Type In-Stock Items
- Condition New
- Related Keywords Dust Sensor, PM2.5 Sensor Module, Dust sensor price, Air Quality Sensor

Description by Manufacturer

S7-L Smart Dust Sensor

Brand：	Luftmy
Work Principle：	Lambert-Beer Law
Country：	China
Output Method：	Digit
Response Time：	0.3s
Lifetime：	≥8 Year
Product Function：	Display The Cleanliness In Real Time
Detection Classification：	Detector
Application Equipment：	Vacuum Cleaner

S7-L Smart Dust Sensor Product Details

1. Description of S7-L Smart Dust

Based on the optical correlation theory, the S7L Smart Dust Sensor can detect the number of particles and concentration data precisely in the handles and extension tubes of vacuum cleaners as well as in the ventilation ducts of sweeping robots, kitchen ventilators, particle detectors, etc.

1.1 Application Benefits of S7-L Smart Dust Sensor for Vacuum Cleaners and Sweeping Robots:

The cleaning effect of the device and the cleanliness of the floors, carpets, bed sheets can be visually presented to the users through the sensor output data and the color display of LED;

The device controls the rotation speed of the motor in an intelligent way in accordance with the sensor data, in order to remain mute, conserve energy and power as well as prolong the life of the motor;

1.2 Product Features of S7-L Smart Dust Sensor:

The product takes use of the correlated and separated structure in emission and reception, with a small size, and is quite easy to be installed and used in various complicated conditions;

The accuracy of motion measurement is high, and the minimum detected particle size is 10um at the wind speed of 12m/s;

The measurement sensitivity is high, with the response time less than 0.6s;Wide measurement range: two measurement options of 0-999 and 0--9999;

Low power consumption: operating current less than 30mA, and dormant current less than 0.5mA.

The output interface contains the LED drive level with the particle concentration of seven colors composed of 3PIN.

The data output interface of particle concentration: PWM and UART can provide accurate dust concentration data for vacuum cleaners, sweeping robots and other devices in real time.

1.3 Application Fields

◆ Vacuum cleaners

◆ Sweeping robots

◆ kitchen ventilators

◆ Intelligent detectors

Price

Price US$ 5 / Unit

Product Image

S7-L Smart Dust Sensor PM2.5 Sensor Module Dust Concentration Sensor Air Quality Sensor Module

Dust Sensor Related Products

S7 Smart Dust Sensor PM2.5 Sensor Price Sensor Module

Download Product Brochure

V2.3.pdf (7.62 Mb)

Company Profile

About Guangzhou Luftmy Intelligence Technology Co., Ltd

Membership Free member
Registration Date2020.05.08
Country/RegionChina
CityGuangzhou
Contact DAI MO(Ms.)

Guangzhou Luftmy Intelligence Technology Co., LTD is jointly found by the institute of automation of Chinese academy of sciences and Fraunhofer laser research institute of Germany Aachen University at the year of 2012, focusing on the technical research, production and sales of photovoltaic particulate sensor .So far, Luftmy's research and development team has more than 50 professional Engineers , including 6 doctors, 13 masters, and over 500 quality &production personnels .

Led by the enterprise culture of "craftsman's dream", Luftmy has gradually become a leading enterprise in the global photovoltaic sensor industry. And by achieving numerous technology breakthroughs and innovation , it has applied and obtained it has applied and obtained 70 invention patents, more than 120 utility model patents and 17 core algorithm software Copyrights.

In 2015, Luftmy reached a strategic cooperation with Germany's Siemens group, which provided great support in technology researching and development, experimental equipment and the establishment of production quality system . In 2017, Siemens - Luftmy sensor research institute was established, focusing on the research and application of sensor technology and algorithm.Luftmy sensor is in the leading position in the same industry in measuring accuracy, stability, consistency error, anti-interference and other performance indicators , at the three consecutive years 2015~2017 years , Luftmy infrared/laser dust sensor has achieved a more than 35% market share in both domestic and foreign shipments , which has been widely praised by the industry.
