Product Attributes

- Place of Origin China
- Supply Type OEM Service
- Condition New
- Related Keywords cnc machine center, small cnc VMC, vocational cnc training, 3 axis cnc VMC

Description by Manufacturer

Features

(1). High performance 3 or 5 axis CNC center machine controller.

(2). The standard spec includes electronic hand wheel.

(3). Selection of high -quality casting materials, more compact.

(4). 8-12 tools ATC.ISO20 spindle type, 24000rpm spindle speed.

(5). USB/U dis/RS232COM etc. many kinds of communication mode, to help users achieve different data transmission and software upgrades easily.

(6). Frequency conversion water cooling motor, low noise, high speed and good durability.

(7). Perfect self-diagnosis function, internal and external status real-time display, alarm immediately when abnormal.

(8). Macro variable, macro definition programming, realizing a variety of logical relations. Support macro program with parameters, convenient to the user programming.

(9). DXF+G code template function, converting DXF automatically to G code for processing.

(10). Graphic simulation function: show the graphics of the processing program and the tool path of the actual operation, tool path simulation processing without controlling the operation of the machine, to exam if the preparation process is correct.

(11). Multi interface selection: support multi language interface display, automatic fault alarm. Processing information display, processing time, the number.

(12). Parameter tabular: Input / output address number setting, only need to fill in the corresponding value in the configuration table.

(13). Applicable industry: technology development, advertising design, art, technical college Education & Training CNC and DIY enthusiasts.

Specification (Technical parameter)

Processing range	X axis stroke X		mm	300
	Y axis stroke Y		mm	175
	Z axis stroke Z		mm	270
	Max. drilling/milling capacity		mm	13
	milling capacity cutter head(max.)		mm	16
	Max. end milling capacity		mm	50
	Spindle to table		mm	115-385
	spindle to column		mm	235
Worktable	Worktable		mm	450x160
	Max loading capacity		kg	75
	*T-slot (widthslot numberspacing)*		mm	3-16-63
Spindle	Main axis speed	Unpowered spindle	rpm	0-3500
		Motorized spindle		100-24000
	Spindle power	Unpowered spindle	W	1100
		Motorized spindle	Kw	2.2
	Spindle taper	Unpowered spindle	/	BT30
		Motorized spindle	/	ISO20
Feed drive	X, Y, Z axis rapid traverse speed	Stapper Motor	mm/min	2500
		Closed loop		6000
		Servo Motor		10000
	Motor voltage	Servo Motor	W	0.75
	X, Y, Z axis torque	Stapper Motor	N.m	3.5
		Closed loop		4.5
		Servo Motor		7.17
	guide rail	Ball screw/hard screw	mm	Hard screw
Tool library	Tool library capacity		pcs	12
	Tool library form		/	Bamboo hat
Positioning accuracy			mm	±0.015
Repeated positioning			mm	±0.01
Handwheel			Yes/No	yes
Cooling system			Yes/No	Cooling water
Lubrication			Manual/Auto	Auto
CNC system			/	XENDOLL
Air pressure			pa	0.55-0.6Mpa
Machine power source			V/Hz	220/54
Machine weight			kg	1500
Product size/dimension			mm	1360x1060x1814

Standard accessories

No.	Tools	Spec.	Qty.
1.	Collet chuck	ISO20-ER20	1
2.	ER20 collect set	φ3.175	1
3.		φ5	1
4.		φ6	1
5.		φ8	1
6.		φ9	1
7.		φ10	1
8.		φ12	1
9.		φ13	1
10.	Spanner wrench	ISO20-ER20	1
11.	Quick vice	Q19D75	1
12.	Hex head bolt	M10302.5	2
13.	Flat Washer	φ10*30	2
14.	T-slot Nut	M10	2
15.	Hex Wrench set (6-piece)	S=2.5	1
16.		S=3	1
17.		S=4	1
18.		S=5	1
19.		S=6	1
20.	Open End Wrench Set (4-piece)	S=8/10	1
21.		S=12/14	1
22.		S=14/17	1
23.	Phillips Screwdriver	φ75*5	1
24.	Flathead Screwdriver	φ75*5	1
25.	Oil bottle	100ml	1
26.	Socket wrench	S=8	1
27.	Socket wrench	S=10	1
28.	Twist drill bit	Ф3	1
29.	Milling cutter	Ф4	1
30.	Milling cutter	Ф6	1
31.	Bakelite Block	505020mm	1
32.	Aluminum Block	505020mm	1
33.	Micro CNC milling manual	VMC300	1
34.	CNC controller manual	Xendoll	1

Optional Accessories

No.	Tools	Spec.
1	Mill Chuck Set	8-piece
2	Quick Vice	100mmS/N:10036
3	Clamping Kit	58-piece
4	Carbide end mill Set	6-piece
5	Fluts Hss end mill Set	7-piece
6	Antimagnetic edge finder	/
7	Indexable carebide end mill	MT3
8	the 4TH axis	/
9	the 5TH axis
10	Z axis tool setter	/
11	Tailstock for the 5^th axis	/
12	MT3 Tapping handle and chuck	3,4,5,6,8mm

Price

Price US$ 1 / Unit

Product Image

Small 3 Axis CNC Machine Center VMC300-05 Vocational CNC Training Tools

Product Video

Small 3 Axis CNC Machine Center VMC300-05 Vocational CNC ...
