TW P2.8 / P3.91 Transparent car rear window LED display car window led display Portable LED Sign China
Transparent car back window LED display is an in-vehicle Portable LED Sign. Comparing to traditional LED screens, the transparent LED screen is more creative in displaying content. As the vehicle moving on the road, the advertising will be appreciated potentially. It won't block out light or the view on both sides. This allows the driver to see traffic behind their vehicle while the screen is not operating.
car window led display Features
High Transparency & High Brightness
The transparency of the NSE transparent car back window LED display
is around 70%. The high transparency will not block out light or view on both interior and exterior sides. It will not affect the driver's observation of the traffic behind the car.
With the high brightness up to 5000nits. The contents showing on the transparent LED screen is able to be vivid even under strong sunlight. Screen use will no longer be limited to weather conditions.
Ultra-slim frame & Ultra-lightweight
Glass wall transparent belongs to the customized LED display cabinet series, The strip length can be customized according to the building structure.
It is widely applied in building glass, shop windows, car showrooms, etc.
Surface Protection
To avoid collisions from the outside environment, NSE designed an acrylic surface to protect the transparent car back window LED display.
We attach great importance on choosing acrylic material to ensure the effect of screen playback remains unchanged.
Lower Power Consumption
The energy-saving driven IC integrated to achieve lower power consumption.
More user -friendly and environmental-friendly.
The transparent car back window LED display is connected to the car battery to work. Energy-saving circuit design will not shorten the life span of car batteries.
Multiple Control Method
To make the operation easily and conveniently, the build-in software of the screen supports 4G, WIFI, USB, and GPS. Remote control, vehicle tracking, and program sending can be easily realized with the help of software. The PC control method is also available if necessary.
Wide application
The transparent car rear window LED display can be applied to all types of car windows by using different brackets. More flexible in installing on the different vehicles.
Specification of NSE Portable LED Sign
|
1
|
Pixel pitch
|
2.8-5.6mm
|
3.9-7.8mm
|
|
2
|
SMD
|
SMD1921(Anti-UV)
|
SMD1921(Anti-UV)
|
|
3
|
Driving Method
|
1/11 scan
|
1/7 scan
|
|
4
|
Cabinet size (W*H)
|
1000*375mm
|
1000*375mm
|
|
5
|
Cabinet resolution
|
356 * 66dots
|
252*48 dots
|
|
6
|
Transparentcy
|
≥52％
|
≥70％
|
|
7
|
Pixel density
|
61952 dots/㎡
|
32256 dots/㎡
|
|
8
|
Driving IC
|
ICN2038
|
ICN2038
|
|
9
|
Cabinet materials
|
Section aluminum
|
Section aluminum
|
|
10
|
Brightness
|
5000 cd/㎡
|
4500 cd/㎡
|
|
11
|
Viewing angle
|
H140°，V140°
|
H140°，V140°
|
|
12
|
Best viewing distance
|
≥4m
|
≥6m
|
|
13
|
Gray scale
|
16bit
|
16bit
|
|
14
|
Refresh rete
|
＞1920HZ
|
＞1920HZ
|
|
15
|
Frame Frequency
|
60 HZ
|
60 HZ
|
|
16
|
Input voltage
|
DC 9-36V
|
DC 9-36V
|
|
17
|
Power consumption（Max/Avg）
|
400/140W/set
|
400/140W/set
|
|
18
|
Screen weight
|
8 kg
|
8 kg
|
|
19
|
MTBF
|
>10,000 hours
|
>10,000 hours
|
|
20
|
Life span
|
≥100,000 hours
|
≥100,000 hours
|
|
21
|
Out-of Control rate
|
＜0.0001
|
＜0.0001
|
|
22
|
Protection grade
|
IP43
|
IP43
|
|
23
|
Work temperature
|
﹣20℃～+60℃or﹣40℃～+60℃
|
﹣20℃～+60℃or﹣40℃～+60℃
|
|
24
|
Humidity(RH)
|
10%-85%RH
|
10%-85%RH
|
|
25
|
Control System
|
4G/WIFI/Network
|
4G/WIFI/Network
|
