Vertical Computer Tension Machine

Add to Basket Share to :

Price

1 - 1
US$ 18500
≥2
US$ 16500

Min Order Quantity1 Set
Supply Ability100
PortTIANJIN XINGANG
Delivery Lead Time45 days for ready goods
Payment Terms 1
Required Quantity

Inquire Now

* Send an Inquiry to this supplier.

Start Order

* Name your price
* Start order doesn't mean buying now

Supplier Info.

Company Name Tianjin Rongsheng Automation Machinery Co.,Ltd
Membership Free member
Registration Date2018.11.29
Country/RegionChina
CityTianjin
Contact Crystal Wang(Ms.)

Report Item

Your report on Product(s) will be sent to EC21 Administrators once submitted.
Then, Administrators will investigate and then take appropriate actions.

Send Report Item

Contact Supplier

* From

Ms.Crystal Wang

Tianjin Rongsheng Automation Machinery Co.,Ltd

* Buying Product

Category : Other Manufacturing & Processing Machinery

- Please enter your specific buying item.
e.g. 42inch LCD TV, leather executive chair

* Messages Use English only Max. 2000 characters. (Min. 20)

Send

EC21.com does not guarantee the validity of product information or the credentials of sellers.

Product Attributes

- Brand Name TJRS
- Model Number VTC4-20
- Place of Origin China
- Supply Type OEM Service
- Condition New
- Related Keywords tension, computer tension, saw blade, machine

Description by Manufacturer

是测定和调整金刚石圆锯张力的设备，直径范围为400mm~2000mm；把基体垂直装在设备之后，不用卸下，在同一条件、同一个轴直接调整和测定张力及端面跳动。
It is a machine for measuring and adjusting the tension of the diamond saw blade. The diameter range is 400mm~2000mm, the largest saw blade diameter is 3000mm. After the substrate is vertically installed on the device, it is not required to remove. The tension and face runout are directly adjusted and measured under the same conditions and on the same axis.

主要特征
Main features
1.由安精密轴承的测定轴和精密法兰盘的工作台组成
  Consists of the precision axis of precision bearings and the precision flange table
2.具有可以调整单方向的气动活塞动作和调整压力性能的测定张力功能
  It has a tension function that can adjust the pneumatic piston movement and adjust the pressure performance in one direction.
3.用油压固定锁住基体
  Secure the substrate with oil pressure
4.调整液压轮倾斜角的功能
  Adjust the tilt angle of the hydraulic wheel
5.自动和手动基体旋转装置，自动张力测定装置
  Automatic and manual base rotating device, automatic tension measuring device
6.非接触式线形传感器，把基体变形可以测定到0.01 mm
  Non-contact linear sensor, the deformation of the substrate can be measured to 0.01 mm
7.完全用电脑系统画出变形和应力曲线，可以打印输出
Fully use computer system to draw deformation and stress curve, print out
8.张力和有关测定的所有技术资料可以储存而于管理
Tension and all technical data related to the determination can be stored and managed

技术资料
Technical Information

型号 Model	VTC 4/20	辊半径 Roll Radius	55mm
电源 Power supply	380V，60Hz（可按要求变更）(can be changed as required)	张力测定压力 Tension measurement pressure	5~30kg
电力消耗 Power Consumption	5KVA	基体旋转 Base Rotation	0~30转/分 0~30 R/min
张力可调整压力 Tension adjustable pressure	400kg~10000kg	设备尺寸 Equipment size	长L 3000mm 宽W 1400mm 高H 1750mm
张力角变更功能 Tension adjustable pressure	最大-3° Maximum -3°
张力角变更功能 Tension adjustable pressure	最大-3° Maximum -3°
辊子速度 Roller speed	15m /分（可以变更） 15m/min (can be changed)	重量 Weight	约2400kg

注Note：
- 可按用户的要求进行特殊变更制造。最大可做到3000mm锯片。
- Special changes can be made according to the user's requirements. Maximum 3000mm saw blade.

Certificates

- CE 714I014611

Price

Price US$ 16500 ~ 18500 / Set

Packaging & Shipping

- PackingOne set in one case
- Packaging Size3100 x 1500 x 1850 ( Millimeters)
- Package Weight 2500 ( Kilograms )
- Delivery Lead Time45 days for ready goods
- Minimum Order 1 Set
- Supply Ability100
- Delivery PortTIANJIN XINGANG
- Shipping Career

Product Image

Tension Related Products

Company Profile

About Tianjin Rongsheng Automation Machinery Co.,Ltd

Membership Free member
Registration Date2018.11.29
Country/RegionChina
CityTianjin
Contact Crystal Wang(Ms.)

Tianjin Rongsheng Automation Machinery Co., Ltd., ,it is a technology company with innovation ability and dedicated to the development, production and service of special machines for diamond tools. The company takes "science and technology as the first, quality first, and sincere service" as its business purpose and is committed to the high-end market of diamond special equipment at home and abroad. In order to cater to the countrys high regard for the development of science and technology, our company has restructured itself. In 2017, we established Tianjin Rongsheng Automation Machinery Co., Ltd. and devoted itself to the development of science and technology. As a top diamond equipment manufacturer in China, we strictly implement the terms of the ISO9001 quality management system and strive to provide customers with more quality products.
Now my company has senior computer program technical engineers and mechanical engineers, as well as professional electricians, milling workers, lathes and a large number of technical personnel and professional equipment. The improvement of hardware and software has ensured the high quality of our products. Our products have been found in many places both at home and abroad. With the hard work and excellent product quality of our employees,we have won praise from customers around the world.
Our main products are automatic high-frequency welding, corel drilling welding machine, automatic volumetric cold press machine, wire bead cold press, front grinding machine, side grinding machine, three sides grinding machine, computer tension machines, resistance welding machines, diamond wrappers, pelletizers, and saw blade polishing machines, etc. These machines have passed the European CE certification.
