WS series horizontal ring winding wrapping machine is widely used in wrapping copper belts, steel belts, aluminum belts, bearings, steel wires, welding wire, cable, rubber tubes, flanges, coil, gaskets, and all kinds of ring products. After winding packing, the product not only has a beautiful appearance but also has a good moisture-proof, dust-proof, rust-proof, anti-aging, anti-accidental loss, and other functions.
Characteristics
1, With a horizontal structure, the product can be packed by lifting, conveying, or manually way.
2, Optional packing material is fixed on the ring, or packing material is fixed on the outside.
3, PLC programmable control machine and man-machine dialogue touchscreen
4, Slide ring automatic precise positioning
5, Adopt taper roller drive, and outer protection roller protection.
6., Lighter products are equipped with upper-pressure rollers.
7, According to the need to adjust the overlapping degree and tightness of the packaging tape.
8, The slide rings can be moved up and down to accommodate products with different inner and outer diameters.
9, Adopt high-wear resistance polyurethane friction wheel and slip ring as integral casting structure Friction wheels enclose anti-wear polyurethane.
10, Optional synchronous winding mechanism, which can complete synchronous winding of two different packaging materials at the same time.
11, The roller can be coated according to the actual needs
Specifications Product type: WS-500F
Wrapping method: Outside hanging or Inside hanging
Product Width: ≤300mm
Product OD: ≤1200mm
Product ID: ≥400mm
Product Weight: ≤30KG
Packaging materials: Stretch wrapping film, woven belt, Composite paper tape, Packaging materials Size: Width:90mm ID:55mm OD:200-450mm
Slide Ring Speed: 70r/min
Countertop height: 750mm
Power: 3.0KW Voltage: AC380V/50Hz
Air supply:6-8kgf/cm²
Product delivery mode: manual operation
*Customized for special specifications.
