SH110 automatic apparent viscosity meter (CCS) conforms to GB/T6538-2010, ASTM D5293 and other technical specifications;
Suitable for testing the low temperature dynamic viscosity index of engine oil.
The instrument can measure the apparent viscosity of oil at temperatures ranging from -35℃ to -5℃ with an interval of 5℃.
It has the advantages of accurate measurement, good repeatability, stable performance and simple operation.
It is suitable for measuring the apparent viscosity of engine oil at -5~-30℃ under the condition of shear stress of about 500 ~ 20000 mPa. S and shear rate of 105~104 s-1.
The instrument adopts automatic temperature control equipment, users only need to operate on the color touch screen can be convenient for testing and analysis.
- ASTM D5293 ASTM D2602 Cooling CCS Method Automatic Engine Oils Apparent Viscosity Tester
- Cold Cranking Simulator (CCS) for Measuring The Apparent Viscosity of Engine Oils
- ASTM D5293 CCS Cold-Cranking Simulator Engine Oil Apparent Viscosity Tester
- Engine Oils CCS Cold Cranking Simulator/Apparent Viscosity Tester
- Engine Oils and Base Stocks Apparent Viscosity Tester by CCS
- ASTM D5293 CCS Cold-Cranking Simulator Engine Oils and Base Stocks Apparent Viscosity Tester
Instrument features:
1, the instrument adopts advanced microcomputer control, touch screen human-computer interaction, calculation, display, printing automation.
2. Language of operation interface: optional setting (Chinese);
3. Imported Omron temperature controller;
Imported compressor duplicated refrigeration, large cooling capacity
4, Automatic detection speed, fine tuning knob to control the current, reduce manual error;
5, Adopt imported motor drive, high precision;
Can store and print experimental results
6. Automatic calculation results after calibration of standard oil;
Adopt embedded operating system, work stably and reliably;
7, the end of the test automatically shut down, and heating, in order to facilitate rapid cleaning,
8, the system can set the temperature according to the user, according to the nonlinear curve to reach the set temperature
9. The user can first calibrate the instrument with standard oil. After the calibration, the relationship between viscosity and motor speed can be described
10. The instrument has calibration function, which can easily and quickly calibrate each part of the system;
Technical parameters
| Temperature measuring range | Normal temperature ~-70 ° C |
| Temperature measuring accuracy | ± 0.1 ° C |
| Stator temperature control accuracy: | ± 0.05 ℃ |
| Enabling environment | 10℃ ~ 40℃ |
| Measuring range | 5000~20000 mPa.s |
| Power | 2.5KW |
| Environment humidity | < 85% |
| Power supply | AC 220V ± 20%(customizable) |
| CCS size: 420mm * 350mm * 520mm Weight: 32kg |
| Refrigeration size: 580mm * 420mm * 550mm Weight: 65kg |
Packing list
| S/N | Name | Quantity | Unit | Remarks |
| 1 | Apparent viscosity tester | 1 | set |
|
| 2 | Cold bath | 1 | set |
|
| 3 | Suction filter pump | 1 | piece |
|
| 4 | Standard oilCL190（50ml） | 1 | bottle |
|
| 5 | Standard oil CL250（100ml） | 1 | bottle |
|
| 6 | Standard oil CL320（50ml） | 1 | bottle |
|
| 7 | Syringe 20ml | 8 | piece |
|
| 8 | Alcohol catheter | 1 | piece |
|
| 9 | power cord | 1 | piece |
|
| 10 | Fuse tube | 1 | piece |
|
| 11 | instruction manual | 1 | copy |
|
| 12 | Packing list | 1 | copy |
|
| 13 | Certificate warranty card | 1 | copy |
|
