Sand Gold Separating Machine Ore Concentrator Separator Machine 5ll Spiral Chute

Add to Basket Share to :

Price

US$ 700

Min Order Quantity1 set / set
Supply Ability1000 sets per month
Portxiamen
Delivery Lead Time 7-15 days

Inquire Now

* Send an Inquiry to this supplier.

Start Order

* Name your price
* Start order doesn't mean buying now

Supplier Info.

Company Name Jiangxi Hengcheng Mining Equipment Co., Ltd.
Membership Free member
Registration Date2012.10.19
Country/RegionChina
CityGanzhou
Contact Jarl Wen(Mr.)

Report Item

Your report on Product(s) will be sent to EC21 Administrators once submitted.
Then, Administrators will investigate and then take appropriate actions.

Send Report Item

Contact Supplier

* From

Mr.Jarl Wen

Jiangxi Hengcheng Mining Equipment Co., Ltd.

* Buying Product

Category : Mining Machinery

- Please enter your specific buying item.
e.g. 42inch LCD TV, leather executive chair

* Messages Use English only Max. 2000 characters. (Min. 20)

Send

EC21.com does not guarantee the validity of product information or the credentials of sellers.

Product Attributes

- Brand Name hengcheng
- Model Number BLL
- Place of Origin China
- application gold,tin,tungsten,iron...
- usage ore separation
- quality Guaranteen Mineral separation
- capacity 0.15-6t/h
- aftersales service life time
- Related Keywords spiral separator, spiral chute, spiral concentrator, gold separating machnine

Description by Manufacturer

Sand Gold Separating Machine Ore Concentrator Separator Machine 5ll Spiral Chute

GENERAL DESCRIPTION:

Spiral chutes are gravity concentrators and separate minerals of different specific gravity according to their relative movement in response to gravity, centrifugal force and other forces in the fluid medium. It has extremely good performance and effects in processing placer of beach, riverside, seashore and stream.

Spiral chutes are made of polyurethane lined fiberglass with wear-resistant corundum inner surface.

MACHINE FEATURES:

Reasonable structure and small occupation area
High recovery, high efficiency, and precise separation,
Light in weight, rust and corrosion resistant;
Simple installation and Minimal maintenance requirements
Low operating cost and long operating life
Reliable running with minimal operator attention
Strong adaptability to fluctuation of feeding amount, density, size and grade;

TECHNICAL DATA:

Model		5LL-1500	5LL-1200	5LL-900	5LL-600	5LL-400
Outside dia(mm)		1500	1200	900	600	400
pitch(mm)		540,720	900,720,540	675,540,405	450,360,270	240,180
Pitch Dia Ratio		0.75,0.6,0.45	0.75,0.6,0.45	0.75,0.6,0.45	0.75,0.6,0.45	0.6,0.45
Lateral slope		9°	9°	9°	9°	9°
Maximum starts per column		4-2	4-2	4-2	3	2
Feeding Size(mm)		0.3-0.02	0.3-0.03	0.3-0.03	0.2-0.02	0.2-0.02
Feeding Density(%)		25-55	25-55	25-55	25-55	25-55
Capacity(T/H)		8-6	4-6	2-3	0.8-1.2	0.15-0.2
External Size	Length(mm)	1560	1360	1060	700	460
	Width(mm)	1560	1360	1060	700	460
	Height(mm)	5230	5230	4000	2600	1500
Weight (Kg)		800	600	400	150	50

APPLICATION IN MINE SITES:

Rutile, ilmenite and zircon concentration

Iron ore, chromite and manganese beneficiation

Tin, tantalum and ore concentration

Gold, native copper and base metal recovery

Silica sands processing

Titano-magnetite concentration

Our service:

Hengcheng machinery is always going for the best quality and perfect service for customers and it has already won lots of praises at home and abroad.

Pre-sales service:
Be a good consultant and assistant to customers, to ensure our customer's investment rewarded with great profit.
1. enough details about the ores or slags shall be learned, sometimes a test is needed for some ores.
2. Equipment of right model is selected for customers.
3. Customized products and processing flow sheet can be designed and developed to meet customer's special needs,
4. Engineer could be sent to observe customer's working site to come up with an optimized solution accordingly.
On-sales service:
Every customer is respected and convenience and reliability will be provided. We are devoted to helping you to benefit as much as possible.
1. Inspection is a must before delivering of the goods.
2. Assistance to make a construction plan by supplying all drawings and data needed.
3. most favorable scheme for you with the guaranteed quality.
4. timely communication to make sure improvement of project and your requirement met.
After-sales service:
1. Installation, adjustment, and testing of equipment is available.
2. Train of technicians and workers at site is promised.
3. Service engineers will not leave until ensuring the whole line running well after the installation & adjustment is finished.
4. if any failure or question about the machines or the processing line, contact us and we are available at any time.

Welcome to visit our factory !

For more details,please visit our website:
http://www.oreshaker.net and
http://www.hengchengmachinery.en.alibaba.com

Price

Price Condition FOB
Price USD 700 / set

Packaging & Shipping

- Packingsteel case or container loading
- Delivery Lead Time 7-15 days
- Minimum Order1 set
- Supply Ability1000 sets per month
- Delivery Portxiamen

Product Image

Sand Gold Separating Machine Ore Concentrator Separator Machine 5ll Spiral Chute

Spiral Separator Related Products

Main Export Markets

- Jiangxi Hengcheng Mining Equipment Co., Ltd. is mainly exporting to Asia, Europe, North America, South America, Australia, Africa

Company Profile

About Jiangxi Hengcheng Mining Equipment Co., Ltd.

Membership Free member
Registration Date2012.10.19
Country/RegionChina
CityGanzhou
Contact Jarl Wen(Mr.)

Jiangxi Hengcheng Mining Equipemt Co., Ltd is specialized in manufacturer of various kinds of mining equipments. We has served the mineral processing industry as an excellent mineral processing equipment manufacturer for over 30 years. Our mining equipment is efficient in .

We are dedicated to providing a complete line of equipments including shaking table, spiral separator, flotation machine, magnetic separator,grinding mill, and so on. We are involved in the range of mineral beneficiation services including mining, flexibility experiment, process design, installation and commissioning, technical consulting, as well as staff training. Our proven technologies and experience permit us to provide our customers with the world's most competitive beneficiation plant and equipments. We are also able to provide the latest innovations through strategic cooperation with Metallurgical Design & Research Institutes, Colleges and Universities.

We are located in Shicheng County, which is convenient to Ganzhou Airport and Xiamen port. As part of plans to expand our global footprint, we are devoting our every effort to provide economically and technically perfect projects outside China. Equipment has already been installed in Indonesia, India, Pakistan, Vietnam, Mongolia, Russia, Mexico, Morocco, Tanzania, Laos and so on.

Satisfaction of the customers is eternal pursuit. We serve our customers with heart and soul and will do whatever we can do to support our customers.

Buying Categories

- Mining Machinery >> Manufacturing & Processing Machinery

Selling Categories

- Manufacturing & Processing Machinery >> Mining Machinery

Keywords

Shaking Table，Spiral Separator，Ball mill，Concentrator

Registration Date	2012/10/19(Year/Month/Date)
Buyer / Seller in EC21	Seller
Business Type	Others
Year established	2011
Employees total	101 - 500
Annual revenue	USD 1,000,001 - 2,000,000

Contact Information Order Credit Report

Company	Jiangxi Hengcheng Mining Equipment Co., Ltd.
Address	Guzhang Industrial Park, Qinjiang Town, Shicheng CountyGanzhouJiangxi342700China
Phone	86 - 0797 - 5711595
Fax	86 - 0797 - 5710595
Homepage	http://www.oreshaker.net
Contact	Jarl Wen
