Product Attributes

- Model Number UAV-R121-1
- Place of Origin China
- Supply Type In-Stock Items
- Condition New
- Related Keywords drone proximity sensor, collision avoidance senso, drone obstacle sensor

Description by Manufacturer

Product Details

UAV-R121-1 drone proximity sensor can detect obstacle distance to drone during flying. It uses 77GHz millimeter wave radar to realize the smart drone collision avoidance and safety secure.

Application Areas

莫之比

Electricity Patrol Drone

莫之比

City Patrol Drone

莫之比

Delivery/Industry Drone

Product Features

Type: Drone Obstacle Avoidance Proximity Sensor

Model: UAV-R121-1

Interface: UART

Protection Level: IP67

Dimensions: 76*71.5*19.6mm

Weight: 87g (Including cables)

Adapted Controller: Pixhawk / Ardupilot / Open Source

莫之比

Product Parameters

Item	Parameters	Data
Antenna Performance	Azimuth	±15°
	Elevation	-5°~+3°
	EIRP(dBm)	30
Detect Performance	Distance detection range	1.5~120m
	Distance detection accuracy	±0.1m
	Distance detection resolution	0.9m
Radar Performance	Frequency	79GHz
	Refresh rate	20Hz
	Bandwidth	0.16GHz
System Property	Working voltage	5-24V
	Working Temperature	-40℃~85℃
	Power Consumption	3W
	Protection rating	IP67
	Communication Interface	UART
	PCB size	55521.6mm

Click for more: https://en.microbrain.com.cn/drone-proximity-collision-avoidance-distance-sensor

Certificates

- CE MRT202003RSH15
- TUV 1210067109TMS
