1.1 Performance characteristics
voltage range wide, DC voltage (9-32) V;
two-channel semiconductor photoelectric
switch control output
can be set to any output starting and ending;
manually set the digital filter ;
set emission intensity according condition;
a serial communication, better compatibility with different scene.
Technical specification
Model | ULM-8920 | |
Measurement range | 3m(The longer can be customized ) | |
Dead zone | 0.3m(can be customized ) | |
Resolution | 0.001m | |
Accuracy | ±0.3%×FS or ±2mm(max) | |
Display | 4 LED | |
Output | No.of channel | Single channel (4~20)mA |
| Loop resistance | RL>600Ω |
Commmunication port | RS-485(Modbus Bus) | |
Control output | No.of Channel | Double channels |
| Electrical contact | Semiconductor photoelectric relay 50mA(Max),AC/DC 30V |
Working power source | Power supply | DC 12V~24V |
| Power Consumption | ≤1.5W |
Working environment | Temperature:(0~50) ℃; Relative humidity: ≤85%RH(none condensation) | |
Storage environment | Temperature:(-40~85) ℃; Pressure: Normal ; Relative humidity: ≤85%RH(none condensation) | |
Protection | IP65 | |
Dimension size | 90mm×200mm×1/2 | |
Installation method | Plug-in pipeline installation, pipe hole size 1/2 | |
