Mineral Test Small Laboratory Ball Mill Price
Specification
XMQ460 * 600 cylinder ball mill, is fully enclosed type dry, wet amphibious continuous
grinding equipment, for building materials (especially cement and ceramic industrial) refractory materials, metallurgy, coal, light industrial chemical, agricultural and industrial laboratories and a half or other small industrial mill fine materials are optional ore research work with, is between continuous grinding and continuous grinding between good a transitional
grinding equipment.
The experiment work is also geology, artificial heavy sand mineral separation before a more
appropriate grinding equipment.
Application
Ball mill is the key equipment for grinding after the crushing process, which is widely used in the manufacture industries, such as cement, silicate, new building material, refractory material, fertilizer, ferrous metal, nonferrous metal and glass ceramics and can be used for the dry and wet grinding for all kinds of ores and other grindable materials.
Working principle of Lab Ball Mill
The ball mill is horizontal cylindrical rotation device, driven by brim gearwheel. There are two chambers and grid. Material goes into the first chamber through the feeding inlet. Inside the first chamber, there are stage liners and ripple liners as well as steel balls. The shell rotates so as to generate electricity, and this force brings ball to a certain height and then balls drop down by gravity, the impact is the grinding force to the material. After the primary grinding, materials go into the second chamber through segregate screen. In the second chamber, there are flat liners and steel ball, after the secondary grinding, material is discharged from the discharging.
The machine is composed by feeding part, discharging part, rotation part and driving part (reducer, small driving gear, electric motor and electric control). The quill shaft adopts cast steel part and the liner is detachable. The rotation big gearwheel is made by cast hobbling processing and the drum is equipped with wear-resistant liner, which has good wear-resistance. The machine is with stable and reliable working condition.
Features of Lab Ball Mill
1. Wide usage, simple structure, convenient maintenance;
2. Big capacity, continuous working;
3. Body liners and grinding medium could be made of various of materials, good corrosion resistance;
4. Easy installation, adjustment, and operation
Technical data:
|
name
|
|
unit
|
|
Cylinder(dia × length)
|
Φ460×600
|
Mm
|
|
Cylinder volume
|
100
|
L
|
|
Cylinder speed
|
48
|
r/min
|
|
Feed Particle
|
2-15
|
mm
|
|
Feeding amount of each time
|
15-30
|
kg
|
|
Processing Capacity
|
Particle
|
0.83
|
0.30
|
0.21
|
0.15
|
0.074
|
Mm
|
|
Mesh Size
|
20
|
48
|
65
|
100
|
200
|
mesh
|
|
Capacity
|
350
|
274
|
130
|
90
|
45
|
Kg/h
|
|
Dimension
|
1600/850/1000
|
Mm
|
|
Weight
|
560
|
kg
|
Company information:
Jiangxi Hengcheng Mining Equipment Company is specialized in manufacturing various kinds of mining equipment. We have served the mineral processing industry as an excellent mineral processing equipment manufacturer for over 20 years.
Hengcheng company is dedicated to provide a complete line of equipment including shaking table, spiral chute, jig machine,trommel,rotary scrubber, flotation machine, magnetic separator,grinding mill, and so on. We are involved in the range of mineral beneficiation services including mineral testing, process flowchart design, installation and commissioning, technical consulting, as well as staff training,etc. Our proven technologies and experience permit us to provide every customer with the most effiicent & commercial beneficiation plant equipment.
Warmly welcome you come to visist our factory.
Our factory located at Ganzhou city, Jiangxi province, China.
